Dry Block Temperature Calibrators (Range: 122 to 662°F) with Thermocouples (T, J, K, N, R, S) for Calibration Labs, Pharmaceutical Divisions Plants Model: AI-DBC-02
4.5 (55 items)
Limited Time Sale$656.40 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 211160090 | Release Date | 2026/04/04 | List Price | $437.60 | Model Number | 211160090 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Range: 122 to 662°F (50 to 350°C) | Accuracy: ± 33.08°F (0.6°C) | Bath Stability: ± 32.09°F(0.05°C) | Stabilization Time: 20 Min. | Heating Time: 30 to 32 Min. 122 to 662°F (50 to 50°C) | Resolution: 0.1°C | Units: °C / °F Switchable | Display: Graphical with LED Backlight | Power Supply: 230V AC ± 5% / 50Hz,1.2 KW for 350DBC
- Transmitter Supply: 24V DC ± 10% (Loop Powered) |Block Diameter: 25.4 mm | Block Depth: 120 mm | Insertion Tube Depth: 110 mm | Temperature Setting: Digital Display through feather touch keypad | Display Stability: ±32.36(0.2°C) | Radial uniformity Fixed Steps for: ±32.54(0.3°C) with similar probes | Switch Test: Continuity check with OPEN / CLOSE indication |
- Measuring Parameters: mA, mV, Volts, Ohms, RTD3 (Pt 100)3 | mA Range: 0 to 25 mA; Resolution: 0.001 mA; Accuracy: ±0.025% of Reading + 10 µA | mV Range: 0 to 1000.0 mV; Resolution: 0.01 mV; Accuracy: ±0.025% of Reading + 0.25 mV | Volts Range: 0 to 10.000 V; Resolution: 0.001 V; Accuracy: ±0.025% of Reading + 3 mV | Ohms Range: 0 to 400 Ohms; Resolution: 0.01 Ohms; Accuracy: ±0.025% of Reading + 0.1 Ohm | RTD3 Range: -200 to 8500 C; Resolution: 0.10 C; Accuracy: ±0.025% of Reading + 0.30 C |
- Thermocouple Types: T, J, K, N, R, S | Thermocouple Range( T,J,K,R,S): -328 to 752°F(-200 to 400°C) ; Resolution: 33.8°F(0.1°C); Accuracy: ±0.025 % of Reading 33.8°F(+ 1°C) |Thermocouple Range(R,S): 572 to 3200°F; Resolution: 33.8°F (1°C) ; Accuracy: ±0.025 % of Reading 33.8°F(+ 1°C )
- Supply Scope: 1 Unit of DBC-02 Dry Block Calibrator, Power Cable, 1 Unit of Test Lead (2 Wire), Insertion Tube: Dual Hole - 1 x 1/4” + 1 x 12.5 mm, Dual Hole - 1 x 1/4” + 1 x 8.2 mm, 1 Unit of Insertion Tool, 2no.s of 6A Spare Fuses, Instruction Manual and Factory Calibration Certificate | Applications: Calibration Labs, Pharmaceutical Divisions, Thermal Plants, Metallurgical Plants.
| Item Weight | 17.6 pounds |
|---|---|
| Manufacturer | INSTRUKART |
| Product Dimensions | 6.1 x 9.45 x 13.78 inches |
